Configured Specifications
Regulator, Pressure Boosting Valve
Regulator
Regulator Type
Electropneumatic
Applicable Fluid
Air
Shape
Standard
Operating Environment
Standard
Exhaust Mechanism
[Not Provided] No
Adverse Current Function
No
Supply Side, Connection Type
Rc
Supply Side, Connection Dia.
1/4
Control Side, Connection Type
Rc
Control Side, Connection Dia.
1/4
Pressure Gauge
[Not Provided] No
Input Signal / Communication Signal
[DC4-20mA] Current Type DC4 ~ 20mA (Sink Type)
Accessory
L-bracket
Pressure Unit
kPa
Custom-made Specifications
None
Specifications
2000 Type
Power Supply Voltage
24 V DC
Monitor Output
Analog output 4 to 20 mA DC (sink type)
Cable Connector Type
Right-angle type 2 m
