Certification
EMC
- EN 55032, EN 55024
EMI
- FCC Part 15 Subpart B (Class B)
EMS
- EN 61000-6-1,
EN 61000-6-3,
EN 61000-4-2,
EN 61000-4-3,
EN 61000-4-4,
EN 61000-4-5,
EN 61000-4-6,
EN 61000-4-8
Environment
Relative Humidity
- 10~95% RH
Operating Temperature
- -40 ~ 70°C (-40 ~ 158°F)
Storage Temperature
- -40 ~ 80°C (-40 ~ 176°F)
Ethernet Communication
RJ-45 Port Connector Type
- 1 x RJ-45
RJ-45 Transmission Speed
- 10/100 Mbps
Mechanism
Enclosure (Metal)
- Metal shell with solid mounting kits
IP Rating
- IP30
LED Indicator
- System: Power, Status
WLAN: Quality, Link/Active
LAN: Link/Active
Serial: Tx, Rx
Mounting (DIN-rail)
- Yes
Mounting (Wall)
- Yes
Weight
- 0.32 kg
Power
Power Consumption
- Max. 2W
Power Input (DC)
- 12 ~ 48 VDC, redundant dual inputs
Software
Configuration
- Windows utility, Telnet console, Web Browser
OS Support
- 32-bit/64-bit Windows XP/Vista/7/8/8.1/10, Windows Server
2003/2008/2008 R2/2012/2012 R2 and Linux
Protocols
- ARP, ICMP, IPv4, IPv6, TCP, UDP, BOOTP, DHCP Client, Auto
IP, Telnet, DNS, SNMP, HTTP, SMTP, SNTP
Reboot Trigger
- Built-in WDT (watchdog timer)
Utility Software
- Advantech Serial Device Server Configuration Utility
Warranty
Warranty Period
- 5 years
Wireless Communication
Wi-Fi 2.4 GHz
- Yes
Wi-Fi 5 GHz
- Yes
Wi-Fi Antenna Connector Type
- Reverse SMA
Wi-Fi Antenna Number
- 2 (support 2T2R)
Wi-Fi Free Space Range
- Open space 100 m
Wi-Fi Network Mode
- Infrastructure
Wireless Security
- WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Wi-Fi Standard
- IEEE 802.11 a/b/g/n
