| Functional principle | Photoelectric proximity sensor | ||||||||||
| Functional principle detail | Background suppression, Optical time-of-flight | ||||||||||
| Housing design (light emission) | Rectangular | ||||||||||
| Sensing range max. | 50 mm … 3,800 mm 1) | ||||||||||
| Sensing range | 100 mm … 3,800 mm 2)
1) |
||||||||||
|
|||||||||||
| Type of light | Visible red light | ||||||||||
| Light source | Laser 6) | ||||||||||
| Light spot size (distance) | Ø 18 mm (3,800 mm) | ||||||||||
| Wave length | 658 nm | ||||||||||
| Laser class | 1 (IEC 60825-1 / CDRH 21 CFR 1040.10 & 1040.11) | ||||||||||
| Adjustment | Single teach-in button (2 x), IO-Link | ||||||||||
|
|||||||||||
1) Object with 6 … 90% remission (based on standard white, DIN 5033).
2) Adjustable.
3) Equivalent to 1 σ.
4) See characteristic curves repeatability.
5) 6% … 90% remission factor.
6) Average service life: 100,000 h at TU = +25 °C.
